Hankook Protec 11NF - Horizontal Lathes

Share Machine

Specifications Print Specs

Model: Protec 11NF

Year: 2012

Stock #: 12938 Sold

Type: Horizontal Lathes

Manufacturer: Used Hankook Machines

Highlights:
Fanuc 32i Model A Control
33" SMW Big Bore Autoblok Front Air Chuck
* 15" Hole Through
33" SMW Big Bore Autoblok Rear Air Chuck
Auto V8 Turret
Heavy Duty Tailstock

2012 HANKOOK Protec 11NF - CNC Horizontal Lathe

Equipped With:

- Fanuc 32i-Model A Control

- Chip Conveyor

- Coolant Tank

- 33" SMW Big Bore Autoblok Front Air Chuck

* Model BB-N-850-375-3-ES

* 15" Hole Through Spindle

- Auto V8 Station Duplomatic Bolt on Turret

- Heavy Duty Tailstock (Loads up to 17,600lbs)

*** Video - Click Here ***

Machine Videos

Machine Specifications

Inch

Metric

Machine Specifications:

CNC Control

yes

Control Type

Fanuc 32i Model A

Chuck Size

33"

Swing

43.3"

Turning Diameter

43.3"

Center Distance

79"

Bar Capacity

15"

Spindle Bore

15"

X Axis Travel

24.4"

Z Axis Travel

79"

Rapid Traverse (X/Z)

236

Spindle Speed (RPM)

400

Spindle Motor

50 HP

Turret Capacity

Tailstock

yes

Y Axis

Live Tooling

Sub Spindle

Dimensions

187" x 109" x 82"

Weight

30,000 pounds

Equipped With:

- Fanuc 32i-Model A Control

- Chip Conveyor

- Coolant Tank

- 33" SMW Big Bore Autoblok Front Air Chuck

* Model BB-N-850-375-3-ES

* 15" Hole Through Spindle

- Auto V8 Station Duplomatic Bolt on Turret

- Heavy Duty Tailstock (Loads up to 17,600lbs)

*** Video - Click Here ***

The Hankook Protec 11NF is an exclusive part of our Horizontal Lathes inventory which we own and service. We're the international CNC specialists with the best guarantee in the industry.
