Mitsubishi LT-520 - Horizontal Lathes

Request Quote
Share Machine
Specifications Print Specs
Model: LT-520
Year: 2015
Stock #: MC0529B
Highlights:
Mitsubishi M70 CNC Control
Parts Catcher
Tool Presetter
Programmable Tailstock

2015 Mitsubishi LT-520 CNC Lathe For Sale
Machine Specifications
CNC Control
yes
Control Type
Mitsubish M70-V
# Axis
2
Swing
20.47"
Turning Diameter
15.75"
Center Distance
27.95"
Chuck Size
10"
Bar Capacity
3.07"
X-Axis Travel
8.6"
Z-Axis Travel
27.95"
Rapid Traverse (X/Z)
794 ipm
Spindle Nose
A2-8
Spindle Speed
3,500 rpm
Main Motor
25 hp
Turret Capacity
10
Tailstock (Yes/No)
yes
Live Tooling
no
Y Axis (Yes / No)
no
Sub Spindle
no
Machine Weight
11,023 pounds

Equipped With:

- Mitsubishi M70-V CNC Control
- Navi Conversational Programming
- Graphics
- Rigid Tapping
- Ethernet
- Chip Conveyor
- Parts Catcher
- Tool Presetter
- Programmable Tailstock
- Coolant Tank & Pump

The Mitsubishi LT-520 is an exclusive part of our Horizontal Lathes inventory which we own and service. We're the international CNC specialists with the best guarantee in the industry.
