Doosan Puma 700L - Horizontal Lathes

Request Quote
Specifications Print Specs
Model: Puma 700L
Year: 2019
Stock #: P700L
Yes
Highlights:
Fanuc 32i Model B Control
Hydraulic Steady Rest Prepped
6.5" Bar Capacity
126" Center Distance

2019 Doosan Puma 700L - CNC Horizontal Lathe
Machine Specifications
Year
2019
Control Type
Fanuc 32i-MB
# Axis
2
Swing
40"
Turning Diameter
35"
Center Distance
126"
Bar Capacity
6.5"
X-Axis Travel
19.7"
Z-Axis Travel
129.1"
X Axis Rapid Feedrate
472 inches-per-minute
Z Axis Rapid Feedrate
394 inches-per-minute
Spindle Speed (RPM)
1,500
Spindle Motor (HP)
50
Spindle Nose
A1-15
Y Axis (Yes / No)
no
Live Tooling (Yes / No)
no
Turret Capacity
12
Tailstock (Yes/No)
yes
Dimensions
343" x 121" x 106"
Weight
51,850 pounds

Equipped With:

- Fanuc 32i Model B Control
- No Chip Conveyor (can be purchased for $14k)
- Coolant Tank & Pump
- Tailstock
- Hydraulic Steady Rest

***PURCHASED THROUGH AN INSURANCE COMPANY. ***SLIGHT SHIPPING DAMAGE TO THE SHEET METAL ON THE BACK OF THE MACHINE







The Doosan Puma 700L is an exclusive part of our Horizontal Lathes inventory which we own and service. We're the international CNC specialists with the best guarantee in the industry.
