Wotan Cutmax 3 - Horizontal Boring Mills (Table)

Share Machine

Specifications Print Specs

Model: Cutmax 3

Year: 1985

Stock #: BR15871 Sold

Type: Horizontal Boring Mills (Table)

Manufacturer: Used Wotan Machines

Highlights:

Equipped With:

Lemoine CNC Control (2015 Retrofit)
Full 4th Axis Built-in Rotary Table
Coolant Thru Spindle
Flood Coolant
Chip Conveyor

Machine Videos

Machine Specifications

Inch

Metric

Machine Specifications:

Control Type

Lemoine

Spindle Size

5.9"

Table Size

78.8" x 78.8"

Max Weight On Table

22,000 pounds

X-Horiz Tvl of Table

98"

Y-Vert Tvl of Head

79"

Z-Axis Travel

78"

W-Axis Travel (Quill)

35.5"

B-Axis (Pallet Indexing)

0.001

Rapid Traverse Rate (X/Y/Z)

315/315/236 IPM

Spindle Speed

2,000 RPM

Spindle Motor

67 Horsepower

Spindle Taper

Cat 50

Coolant Thru Spindle

yes

Weight

59,400 pounds

Equipped With:

Lemoine CNC Control (2,015 Retrofit)
Full 4th Axis Built-in Rotary Table
Coolant Thru Spindle
Flood Coolant
Chip Conveyor

The Wotan Cutmax 3 is an exclusive part of our Horizontal Boring Mills (Table) inventory which we own and service. We're the international CNC specialists with the best guarantee in the industry.
