Equipped With:
Table....... 33.5" x 63"
Table Load..10,120 lbs
Travels (60" x 36" x 30")
Rapids....(X,Y,Z) 943 ipm
Spindle Nose to Table Top...... 5.9" - 35.9"
Spindle Speeds............ 15,000 RPM
Spindle Taper............... HSK 100a (50 Taper)
Tool Changer................ 30 atc
Equipped With:
Fanuc 18I MB CNC Control
Data Server
Heidenhain Scales
Ethernet
High Precision Contour Control (HPCC)
Chip Conveyor
Coolant Thru Spindle
Chiller
Tooling Available at Additional Cost
The Johnford DMC-1500H is an exclusive part of our Machining Centers, Gantry (incld. Bridge & Double Column) inventory which we own and service. We're the international CNC specialists with the best guarantee in the industry.
