Makino A-61NX - Horizontal Machining Centers

Share Machine
Specifications Print Specs
Model: A-61NX
Year: 2011
Stock #: 13825 Sold
Highlights:

Makino A-61NX CNC Horizontal Machining Center, Fanuc Pro 5 Control, 28.7
Machine Specifications
CNC Control
yes
Control Type
PROFESSIONAL 5
# Axis
4
Pallet-W
19.7"
Pallet-L
19.7"
Pallet Capacity
1,100 pounds
Pallet Indexing (B-Axis)
.1
X
28.7"
Y
25.6"
Z
31.5"
X-Axis Rapid Feedrate
1,968 ipm
Y-Axis Rapid Feedrate
1,968 ipm
Z-Axis Rapid Feedrate
1,968 ipm
Spindle Speed
14,000
Spindle Taper
HSK 63
Tool Changer Capacity
60
Power
30 horsepower
Weight
26,900 pounds

Equipped With:

Hydraulic Clamping
Data Center (1GB)
Helical Interpolation
1,050 Registered programs
Chip Conveyor
Coolant Thru Spindle
Full 4th Axis
Coolant Tank & PumpS
Approx 45 tool holders

The Makino A-61NX is an exclusive part of our Horizontal Machining Centers inventory which we own and service. We're the international CNC specialists with the best guarantee in the industry.
