Okuma MACTURN 350W - Lathes (3-Axis or More)

Share Machine
Specifications Print Specs
Model: MACTURN 350W
Year: 2004
Stock #: BR16006 Sold
Yes
Highlights:

Okuma MacTurn 350W 5-Axis CNC Turn/Mill Center, OSP E100, (2) 10
Machine Videos
Machine Specifications
# Axis
5
Control Type
OSP-E100 Control
Chuck Size
10"
Spindle Nose
A2-8
Swing
21.65"
Turning Diameter
20.87"
Bar Capacity
2"
C-Axis
yes
X Axis Travel
19.88"
Z Axis Travel
65.75"
Spindle Speed (1) (RPM)
5,000
Main Motor
30 Horsepower
Sub Spindle Chuck Size
10"
Sub Spindle Speed (RPM)
5,000
Sub Spindle Motor
15 Horsepower
Live Milling (Yes / No)
yes
Live Milling Speed (RPM)
12,000
Tool Changer Capacity
84
Weight
32,000 pounds

Equipped With:

12k RPM Milling Spindle (1 Degree B Axis)
(Y) Axis
One Touch IGF (Conversational Programming)
Mac Man
Helical Cutting
Syncho Tap
Plane Conversion
96 tool Offsets
(Y) Axis Barrier
Simultaneous 5 Axis Machining
Tool Probe
Sub Spindle
Chip Conveyor
Captco C6 Spindle Taper
Transformer
Lots of Tooling

The Okuma MACTURN 350W is an exclusive part of our Lathes (3-Axis or More) inventory which we own and service. We're the international CNC specialists with the best guarantee in the industry.
