Yama Seiki AWEA 4025Z - Machining Centers, Gantry (incld. Bridge & Double Column)

Share Machine
Specifications Print Specs
Model: AWEA 4025Z
Year: 2015
Stock #: BR15889 Sold
Highlights:

YAMA SEIKI AWEA LP 4025Z BRIDGE TYPE VERTICAL MACHINING CENTER
Machine Specifications
Control Type
FANUC 31i MODEL B
Distance Between Columns
106"
Table-W
94"
Table-L
158"
X
158"
Y
98.4"
Z
40"
Spindle Nose to Table
7.8-47.2"
Taper
CAT50
RPM
4,500
Power
35 horsepower
Rapid Traverse Rate (X/Y/Z)
590 IPM
Cutting Feedrates (X/Y/Z)
393 IPM
Coolant Thru Spindle
yes
# ATC
60
Table Load Capacity
33,000 pounds
Weight
88,000 pounds

Equipped With:

RIGHT ANGLE HEAD ATTACHMENT SEMI AUTO LOADING 2.5 DEGREE AUTO INDEX
CHIP BLASTER UNIT
1000 PSI COOLANT THROUGH SPINDLE
CHIP CONVEYOR
LARGE ASSORTMENT OF CAT50 TOOL HOLDERS
LASER PROBE
AWEA 2 SPEED GEAR BOX FOR SPINDLE DRIVE

The Yama Seiki AWEA 4025Z is an exclusive part of our Machining Centers, Gantry (incld. Bridge & Double Column) inventory which we own and service. We're the international CNC specialists with the best guarantee in the industry.
